Rock Fiber Panel Ceiling Substrate Lightweight & Acoustic Class A Non Combustible

Rock Fiber Panel Ceiling Substrate Lightweight & Acoustic Class A Non Combustible

Lightweight rigid mineral wool board

Ceiling rigid mineral wool board

Acoustic rigid rock wool board

Place of Origin:

china

Chat Now
Request A Quote
Product Details
Density:
1000-1200 Kg/m³
Flexural Strength:
≥25 MPa
Fire Performance:
Class A, Non-combustible
Formaldehyde Emission:
0.014 Mg/m³
TVOC Emission:
0.02 Mg/(m²·h)
Screw Holding Capacity:
1300 N
Highlight:

Lightweight rigid mineral wool board

,

Ceiling rigid mineral wool board

,

Acoustic rigid rock wool board

Payment & Shipping Terms
Minimum Order Quantity
1 container.
Payment Terms
L/C,T/T
Product Description
Rock Fiber Panel - Ceiling Substrate - Lightweight & Acoustic Class A Non-Combustible
Product Overview

This lightweight rock fiber panel is specifically developed for suspended ceiling systems. Engineered with Class A non-combustibility, it offers optimized weight and superior acoustic performance. The open-pore structure combined with a dense surface effectively absorbs reverberation noise while providing a flat, reliable base for gypsum, metal, or other ceiling finishes.

Applications

Ideal ceiling substrate for public spaces including offices, conference rooms, theaters, and subway stations. Suitable for concealed grid systems or composite applications with exposed mineral wool panels.

Technical Specifications
Parameter Unit Typical Value
Density kg/m³ 1000-1200
Flexural strength MPa ≥25
Fire performance Class A, non-combustible
Formaldehyde emission mg/m³ 0.014
TVOC mg/(m²·h) 0.02
Moisture Swelling Rate % 0.05
24-hour water absorption thickness expansion rate % 0
Screw Holding Capacity N 1300
Product Features
  • Class A non-combustible rating ensures superior fire safety in ceiling plenums
  • Thin and lightweight design significantly reduces ceiling load
  • NRC ≥ 0.65 effectively lowers room reverberation and improves acoustic comfort
  • Excellent dimensional stability prevents humidity-induced warping
  • Quick installation with grid systems, ideal for large area applications
Rock Fiber Panel product illustration showing ceiling substrate application
