Rock Fiber Panel Raised Flooring Backing Panel High Strength Load Bearing

Rock Fiber Panel Raised Flooring Backing Panel High Strength Load Bearing

Flooring rigid mineral fiber insulation

impact resistance rigid mineral fiber insulation

Flooring rock wool insulation board

Place of Origin:

china

Chat Now
Request A Quote
Product Details
Density:
1000-1200 Kg/m³
Flexural Strength:
≥25 MPa
Formaldehyde Emission:
0.014 Mg/m³
TVOC Emission:
0.02 Mg/(m²*h)
Moisture Swelling Rate:
0.05%
Screw Holding Capacity:
1300 N
Highlight:

Flooring rigid mineral fiber insulation

,

impact resistance rigid mineral fiber insulation

,

Flooring rock wool insulation board

Payment & Shipping Terms
Minimum Order Quantity
1 container
Payment Terms
L/C,T/T
Product Description
Rock Fiber Panel - Raised Flooring Backing Panel - High-Strength Load-Bearing Class A Non-Combustible
Product Description

High-density rock fiber panel designed for raised flooring systems in data centers, server rooms, clean rooms, and prefabricated houses. Class A non-combustible with outstanding compression and impact resistance. Acting as a filling substrate between pedestals and top panels, it evenly distributes point loads, prevents surface deformation, and provides a halogen-free, anti-static fire barrier.

Applications

Intermediate sub-core or filling layer for raised floor systems in data centers, telecom rooms, clean workshops, and prefabricated houses, anti-static flooring.

Specifications
Parameter Unit Typical Value
Density kg/m³ 1000-1200
Flexural strength MPa ≥25
Fire performance -- Class A, non-combustible
Formaldehyde emission mg/m³ 0.014
TVOC mg/(m²*h) 0.02
Moisture Swelling Rate % 0.05
24-hour water absorption thickness expansion rate % 0
Screw Holding Capacity N 1300
Rock Fiber Panel technical diagram and installation illustration
Key Features
  • Class A non-combustible, meets fire codes for equipment rooms
  • High compressive strength, suitable for heavy equipment areas
  • Halogen-free and environmentally friendly, no corrosive gases in fire
  • Thickness tolerance ±0.05mm, ensures floor flatness
